NXT-G Programs for SuGO.
Used Lego Nxt
Note: This page is for the NXT Brick. If you have a new EV3 Mindstorms kit, go to the EV3 page.
In order for a SuGObot to be able to play, it needs a program. This program must know how to read the line and eye sensors, and drive the motors to perform the game strategy.
When we run our monthly ' SuGO Sunday' competitions at GEARS, we require that all the SuGO bots are pre-loaded with the same standard program. Roblox on mac. This way the robots all use a similar strategy, so it's all up to the mechanical design and game play to produce a winning SuGObot.
However, for other competitions, if people are designing their own robots at home and bringing them to a 'Bring'n Battle' style competition, there's no reason why the team can't also develop it's own programs.
A SuGO program can be written in many different languages. The most common programming language used for the MINDSTORMS NXT is NXT-G. NXT-G is the graphical language that comes bundled with the retail NXT kit.
You can also use C, LabVIEW or even Java to program the NXT, but for this page, we'll limit our discussion to NXT-G. Windows 7 loader latest version.
NXT-G Programs
The following program files are known as a Pack and Go files. They have an .rbtx extension. Mini militia unlimited ammo. This file not only contains the main program, but it also contains all the other files needed to run the program (eg: sound files, MyBlocks etc.) If you download this file, you can open it with NXT-G Version 2.0 or later, and then download it into the NXT.
Two Styles of SuGObot programs are presented here. The first PV1 style assumes that the robot has two light sensors to detect the black line around the ring. The second C2 style assumes you have one lignt sensor, and one color sensor. Depending on what type of sensors you have, you should download the corrosponding programs and manuals.
Lego Nxt 2.0 Software Download
PV1 programs for Two Light sensors and the LEGO Education version of NXT-G.
| SuGO_PV1.rbtx(Note: make sure you save this as a .rbtx file) The first Pack and Go file is for a program called 'SuGO PV1'. This is the main SuGO program used to play a SuGO match. When you run the program it counts down 5 seconds, then calibrates the line sensors and starts hunting for the opponent. Another usefull Pack and Go file is for a program called 'Mechanic PV1'. This program is used to check the wiring and sensors on your SuGObot before you get on the playing field. The program puts the SuGObot through some simple movements, and then speaks what it sees from its sensors. The program lets you reverse the motor directions in case your motor configuration causes the robot to move backwards instead of forwards. Mechanic_PV1.rbtx(Note: make sure you save this as a .rbtx file) There is also a Mechanic PV1 User Guide, that explains how to use the program to check your SuGObot. Teams should print this out, and have it with them whenever they build, and need to test their SuGObot. |
| SuGO_C2.rbtx(Note: make sure you save this as a .rbtx file) The first Pack and Go file is for a program called 'SuGO_C2'. This is the main SuGO program used to play a SuGO match. When you run the program it counts down 5 seconds, then calibrates the line sensors and starts hunting for the opponent. Another usefull Pack and Go file is for a program called 'Mechanic_C2'. This program is used to check the wiring and sensors on your SuGObot before you get on the playing field. The program puts the SuGObot through some simple movements, and then speaks what it sees from its sensors. The program lets you reverse the motor directions in case your motor configuration causes the robot to move backwards instead of forwards. Mechanic_C2.rbtx(Note: make sure you save this as a .rbtx file) There is also a Mechanic C2 User Guide, that explains how to use the program to check your SuGObot. Teams should print this out, and have it with them whenever they build, and need to test their SuGObot. |
Good Programming Practices.
At GEARS we are FIRM believers in taking the time to develop Good Programming Practices. These two programs are good illustrations of what we mean by that.
Both programs make strong use of Subroutines (or MyBlocks). These appear as blocks with a teal colored band across them. Each MyBlock can be double clicked to show further detail. The idea is that MyBlocks enable the program to be divided into smaler portions that can be tested or modified independantly. MyBlocks can also be shared between programs to make it easier to create new SuGO programs with more sophisticated strategies, based on pre-tested functions.
Lego Mindstorms Nxt 2.0 Download
These programs also make extensive use of text files to save SuGO setup information, and variables to share this information between the different MyBlocks.
